What's in the package:
• RowErg simulator
• PM5 monitor
• Phone/Tablet holder
• User manual
• Performance Monitor guide
• Assembly tools and illustrated instructions for the simulator
How to assemble the simulator:
Before using the RowErg simulator for the first time, attach the front legs (8 screws) and connect the track to the front part of the simulator. The necessary tools and detailed instructions are included.
| Total length | 244 cm |
|---|---|
| Width | 61 cm |
| Seat height from ground | Standard: 36 cm |
| Track length of seat | 137 cm (additional track available for purchase) |
| Chain | Nickel-plated steel chain |
| Monitor | PM5 (powered by two D batteries; during exercise, the monitor draws energy from the flywheel for autonomous operation with batteries) |
| Maximum user weight | 227 kg, tested according to Concept2 |
| 135 kg according to European standard EN 20957-7 for testing fitness equipment | |
| Frame | Aluminum frame |
| Standard: Aluminum front legs, steel rear legs | |
| Assembled device dimensions | 244 cm x 61 cm |
| Disassembled device dimensions | Standard: 64 x 84 x 137 cm |
| Recommended workout space size | 300 cm x 130 cm |
| Device weight | Standard: 26 kg |
| Packaging dimensions | Standard: 1 package: 38x55x144 cm / 32 kg |
Concept2 rowing simulators are renowned for their quality, durability, and ease of maintenance. To ensure long and reliable operation, we recommend:
• Wiping down the handle, track, and wheels of the seat with a damp cloth after each use.
• Checking the chain for flexibility approximately every 50 hours of use or once a year, and lubricating if necessary. If lubrication doesn't improve flexibility, the chain should be replaced.
• If the handle doesn't return to the flywheel frame, shorten/tighten the return elastic. After several adjustments, replace the elastic.
• Periodically inspecting the connection link between the chain and the simulator handle. If worn, replace it.
• If the simulator no longer provides proper resistance, open and clean the spiral damper and flywheel. Cleaning is recommended at least once a year.
• After initial workouts, periodically check and tighten the screws on the simulator as needed.
• 2 years for all moving parts (rollers, bearings) of the simulator and monitor (excluding monitor batteries)
• 5 years for the frame or individual parts of the frame
Measure of excellence
RowErg has become the benchmark for rowing programs and also for athletes in other disciplines around the world. Our PM monitor provides precise and comparable workout results, allowing you to track progress and compare with others. Due to this comparability, RowErg is used at various events and competitions worldwide, and with the ErgData app, the online leaderboard already contains over a million results from different challenges.
For Everyone
Whether you want to improve your fitness, monitor your weight, or train for the Olympics, RowErg helps you achieve your goals. It offers low-impact movement that works all major muscle groups, providing effective exercise. The resistance system uses air flow, so resistance depends on your pulling force. Easily adjustable airflow allows for further resistance customization, making RowErg suitable for home users, professional athletes, and everyone in between.
PM5 Monitor
The PM5 monitor is advanced yet incredibly easy to use. Accurate, comparable data on strokes, intervals, or entire workouts allow precise tracking of your training and fitness. Powered by just two D batteries, it offers long-lasting, reliable operation.
The Concept2 Utility software enables you to save your workouts to your account and easily update the monitor’s firmware.
ErgData and Other Compatible Apps
ErgData is a free app that connects the PM monitor with iOS and Android devices. It records and stores all your workouts in your Concept2 LogBook account and allows you to compare with selected training partners. Additionally, the app supports group training 'from a distance' in real-time loop mode, access to 'C2 Workout of the Day,' live progress tracking, and analysis.
Durable and Easy to Maintain
All Concept2 devices are known for their high build quality. Designed to withstand intensive use in gyms, rowing clubs, and homes, they are also simple to maintain, so you can focus on using them rather than servicing.
One Device – Two Sizes
RowErg is available with standard or higher legs. The seat height is 36 cm with standard legs and 51 cm with higher ones. The taller frame makes sitting and standing easier, which is especially helpful for people with knee or mobility issues. The higher version is also recommended for gyms where a treadmill runs alongside the RowErg, so users don’t have to step over the rowing path during workouts.
Easy Storage
The RowErg quickly and easily separates into two parts for storage (no tools required) and features wheels for easy movement. It can also be stored assembled in a vertical position. Ideal for homes or gyms where space flexibility is needed.
